Yamaha F100D Service Manual

6D93G11
4-8
1
2
3
4
5
6
7
8
9
4
No. Part name Q’ty Remarks
1 Intake manifold 1
2 Sensor assembly 1
3Screw 4 ø5
×
13 mm
4O-ring 1
Not reusable
5 Idle speed control 1
6O-ring 1
Not reusable
7 Throttle body assembly 1
8Bolt 3 M6
×
16 mm
9Gasket 1
Not reusable
10 Throttle position sensor 1
11 Screw 2
12 O-ring 1
Not reusable
13 Fuel injector 4
14 O-ring set 4
Not reusable
15 Fuel rail 1
16 Bolt 2 M6
×
38 mm
S6D84050
3
2
4
5
3
6
11
10
12
7
8
9
1
13
14
15
16
16
T
R
.
.
3.7 N
·
m (0.37 kgf
·
m, 2.7 ft
·
lb)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
Intake manifold
