Operation
60
EMU37323
Checking the fuel filter
Check that the fuel filter is clean and free of
water. If any water is found in the fuel, or if a
significant amount of debris is found, the fuel
tank should be checked and cleaned by a
Yamaha dealer.
EMU41771
Controls
Turn the main switch “ ” (on) and make
sure that the Digital electronic control-ac-
tive indicator comes on.
Turn the steering wheel full-right and full-
left. Make sure operation is smooth and un-
restricted throughout the whole range with
no binding or excessive free play.
Operate the throttle levers several times to
make sure there is no hesitation in their
travel. Operation should be smooth over
the complete range of motion, and each le-
ver should return completely to the idle po-
sition.
EMU40363
Engine shut-off cord (lanyard)
Check the engine shut-off cord and clip for
damage, such as cuts, breaks, and wear.
EMU40994
Engine oil
1. Place the outboard motor in a vertical
position (not tilted). NO TICE : If the out-
board motor is not level, the oil level
indicated on the oil dipstick may not
be accurate.
[ECM01862]
2. Remove the oil dipstick and wipe it
clean.
3. Insert the oil dipstick completely and re-
move it again.
4. Check that the oil level on the oil dipstick
is between the upper and lower marks.
Consult your Yamaha dealer if the oil lev-
el is not at the proper level or if it appears
milky or dirty.
1. Fuel filter
1. Clip
2. Engine shut-off cord (lanyard)
1. Oil dipstick
U6DV37E0.book Page 60 Monday, December 10, 2018 4:07 PM
