7-5
OPTIONAL EQUIPMENT
TRANSOM MULTI-SENSOR (6Y9)
IMMOBILIZER UNIT
Yamaha Security System limits the
engin
e speed to the specified level.
Part No.
Remarks
6Y9-83688-00
Depth, sp
eed, water surface temp
Part No.
Remarks
6Y8-86254-02
For EU (STD)
6Y8-86254-22
For US, ANZ
6Y8-86254-30
For JPN
157 (6.20)
4
9
00 (1
9
3)
70 (2.77)
99
(3.
9
0)
227 (8.
9
5)
T
o network hub
via wire-lead
6Y
9
-83553-60
mm (in.)
2400 (
9
4.5)
200 (7.87)
(WHT)
104 (4.0
9
)
9
(0.35)
112 (4.41)
128 (5.04)
9
(0.35)
146 (5.75)
6.
9
(0.27)
8.5
(0.33)
36
(1.42)
R
mm (in.)
