Yamaha F70AET User Manual

9-22
IMMOBILIZER RIGGING KIT CONTENTS
IMMOBILIZER KIT 1 (FOR US, ANZ, CRB)
Kit P/N: 6Y8-W0035-83
IMMOBILIZER KIT 2 (FOR JPN)
Kit P/N: 6Y8-W0035-92
SINGLE ENGINE GAUGE KIT FOR IMMOBILIZER (FOR EU, ANZ, JPN, GEN)
P/N: 6Y8-W0035-A2 (w/ IG SW panel)
Part No. Part name Q’ty Remarks
6Y8-86254-22 Immobilizer unit 1 Conformed to local frequency band
90167-06M00 Screw 4
97880-06035 Screw 4
90201-06M30 Washer 8
95780-06300 Nut 4
6Y8-82521-11 Pigtail bus wire 1 0.3 m (1 ft)
6Y8-48277-00 Symbol graphic 4
6Y8-28107-94 Instruction 1
Part No. Part name Q’ty Remarks
6Y8-86254-30 Immobilizer unit 1 Conformed to local frequency band
90167-06M00 Screw 4
97880-06035 Screw 4
90201-06M30 Washer 8
95780-06300 Nut 4
6Y8-82521-11 Pigtail bus wire 1 0.3 m (1 ft)
6Y8-48277-00 Symbol graphic 3
6Y8-28107-94 Instruction 1
Part No. Part name Q’ty Remarks
6Y8-8350T-01 SQR tachometer 1
6Y8-83500-01 SQR speed/fuel gauge 1
6Y8-81920-01 Multi-hub 2 w/ resistor
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1
6Y8-82582-11 4-pin waterproof cap 3 White
6Y8-82582-01 2-pin waterproof cap 1 Red
6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 2
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1
6Y8-8356N-01 Fuel tank/ GPS wire 1 NMEA0183
6Y8-83553-01 PWR supply wire 1 w/ 10 amp fuse
6X6-82570-31 IG switch panel, single 1 OFF-ON-START
6X6-8258A-30 Main wire-harness, 10 m (33 ft) 1 16-pin
6Y9-2819K-E0 Set up manual 1
6Y8-2819U-20 Operation Manual 1
