IMMOBILIZER RIGGING KIT CONTENTS
SINGLE ENGINE GAUGE KIT FOR IMMOBILIZER (FOR EU, ANZ, JPN, GEN)
P/N: 6Y8-W0035-D1 (w/o IG SW panel)
TWIN ENGINE GAUGE KIT FOR IMMOBILIZER
P/N: 6Y8-W0035-B1
Part No. Part name Q’ty Remarks
6X6-8258A-30 Main wire-harness, 10 m (33 ft) 1 16-pin
6Y8-81920-01 Multi-hub 2
6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 2
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1
6Y8-82582-01 2-pin waterproof cap 1 Red
6Y8-82582-11 4-pin waterproof cap 3 White
6Y8-83500-01 SQR speed/fuel gauge 1 NMEA0183
6Y8-8350T-01 SQR tachometer 1
6Y8-83553-01 PWR supply wire 1 w/ 10 amp fuse
6Y8-8356N-01 Fuel tank/GPS wire 1
6Y9-2819K-E0 Set-up manual 1
6Y8-2819U-70 Operation Manual 1 1
6Y8-2819U-80 Operation Manual 2 1
Part No. Part name Q’ty Remarks
6Y8-8350T-01 SQR tachometer 2
6Y8-8350F-01 SQR fuel MGT gauge 1
6Y8-8350S-01 SQR speedometer 1
6Y8-81920-01 Multi-hub 3 w/ resistor
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 2
6Y8-82582-11 4-pin waterproof cap 3 White
6Y8-82582-01 2-pin waterproof cap 2 Red
6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 4
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 2
6Y8-8356N-01 Fuel tank/GPS wire 1 NMEA0183
6Y8-83553-01 PWR supply wire 1 w/ 10 amp fuse
6X6-82570-40 IG switch, twin 1 OFF-ON
6X6-82570-60 Start/stop SW, twin 1
6X6-8258A-40 Main wire-harness, 12.2 m (40 ft) 2 16-pin
6Y9-2819K-E0 Set up manual 1
6Y8-2819U-70 Operation Manual 1 1
6Y8-2819U-80 Operation Manual 2 1
