Yamaha FZ-09 User Manual

1. Dimmer switch
2. Pass switch
3. Turn signal
sw itch
4. Horn switch
5. Clutch
sw itch
6. Oil level switch
7. Sidestand switch
8. Ha zard switch
9. Start/engi ne stop switch
10. Drive mode
sw itch
1
1. Front brake li ght switch
1
2. Main sw itch
13. Rear brake light switch
ELECTRICAL COMPONENTS
8-90

Yamaha FZ-09 Specifications

General

Bore x Stroke	78.0mm x 59.1mm
Compression Ratio	11.5:1
Final Drive	Chain
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Seat Height	32.1 in
Wheelbase	56.7 in
Fuel Economy	44 mpg
Wet Weight	414 lb
Fuel Delivery	Fuel injection
Ignition	TCI
Transmission	6-speed
Front Suspension	Inverted fork, 5.4-in travel
Rear Suspension	Single shock, 5.1-in travel
Front Brakes	Dual hydraulic disc, 298 mm
Rear Brakes	Hydraulic disc, 245 mm
Rake (Caster Angle)	25°
Horsepower	115 hp @ 10, 000 rpm
