Yamaha MT-10 2020 User Manual

Special features
4-6
1
2
3
4
5
6
7
8
9
10
11
12
2. Wait a few seconds and then turn
the key back to “ON”.
3. The “ ” indicator light should turn
off and the system be enabled.
TIP
If the “ ” indicator light remains on af-
ter resetting, the vehicle may still be rid-
den; however, have a Yamaha dealer
check the vehicle as soon as possible.
4. Have a Yamaha dealer check the
vehicle and turn off the “ ” warn-
ing light.
EAU79481
Quick shift system
The quick shift system allows for
full-throttle, clutch lever-less upshifts.
When the shift switch detects motion in
the shift pedal, engine power and drive
torque are momentarily adjusted to al-
low the upshift to occur.
TIP
The quick shift system operates when
traveling at least 20 km/h (12 mi/h) with
an engine speed of 2000 r/min or high-
er, and only when accelerating. It does
not operate when the clutch lever is
pulled.
NOTICE
ECA26260
To prevent drivetrain damage, al-
ways use the clutch lever to shift
when riding at slow speed, when
downshifting, or if the quick shift
system is off.
1. Quick shift icon “QS”
2. Shift switch
1
2
B67-9-13.book 6 ページ ２０１９年７月１９日 金曜日 午後２時５６分

Yamaha MT-10 2020 Specifications

General

Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel Injection
Transmission	6-speed
Front Suspension	43mm inverted fork, fully adjustable
Front Brakes	Dual 320mm hydraulic disc, ABS
Rear Brakes	220mm hydraulic disc, ABS
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Seat Height	825 mm
Starter System	Electric
Final Drive	Chain
Width	800 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Fuel Capacity	17 liters
Horsepower	160 HP
Maximum Power	160 HP @ 11500 rpm
Maximum Torque	111 Nm @ 9000 rpm
Length	2, 095 mm
Height	1110 mm
Wheelbase	1, 405 mm
Torque	111 Nm
