Yamaha MT-10 2020 User Manual

Instrument and control functions
5-17
1
2
3
4
5
6
7
8
9
10
11
12
EAU13076
Fuel tank cap
To open the fuel tank cap
Open the fuel tank cap lock cover, in-
sert the key into the lock, and then turn
it 1/4 turn clockwise. The lock will be re-
leased and the fuel tank cap can be
opened.
To close the fuel tank cap
With the key still inserted in the lock,
push down the fuel tank cap. Turn the
key 1/4 turn counterclockwise, remove
it, and then close the lock cover.
TIP
The fuel tank cap cannot be closed un-
less the key is in the lock. In addition,
the key cannot be removed if the cap is
not properly closed and locked.
WARNING
EWA11092
Make sure that the fuel tank cap is
properly closed after filling fuel.
Leaking fuel is a fire hazard.
1. Front wheel sensor rotor
2. Front wheel sensor
1. Rear wheel sensor rotor
2. Rear wheel sensor
2
1
2
1
1. Fuel tank cap lock cover
2. Unlock.
1
2
B67-9-13.book 17 ページ ２０１９年７月１９日 金曜日 午後２時５６分

Yamaha MT-10 2020 Specifications

General

Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel Injection
Transmission	6-speed
Front Suspension	43mm inverted fork, fully adjustable
Front Brakes	Dual 320mm hydraulic disc, ABS
Rear Brakes	220mm hydraulic disc, ABS
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Seat Height	825 mm
Starter System	Electric
Final Drive	Chain
Width	800 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Fuel Capacity	17 liters
Horsepower	160 HP
Maximum Power	160 HP @ 11500 rpm
Maximum Torque	111 Nm @ 9000 rpm
Length	2, 095 mm
Height	1110 mm
Wheelbase	1, 405 mm
Torque	111 Nm
