Yamaha MT-10 2020 User Manual

Instrument and control functions
5-26
1
2
3
4
5
6
7
8
9
10
11
12
EAU15152
Luggage strap holders
There is a luggage strap holder on each
passenger footrest.
EAU67050
EXUP system
This model is equipped with Yamaha’s
EXUP (EXhaust Ultimate Power valve)
system. This system boosts engine
power by means of a valve that controls
exhaust flow within the exhaust cham-
ber.
NOTICE
ECA15611
The EXUP system has been set and
extensively tested at the Yamaha
factory. Changing these settings
without sufficient technical knowl-
edge may result in poor perfor-
mance of or damage to the engine.
EAU49454
Auxiliary DC jack
A 12-V accessory connected to the
auxiliary DC jack can be used when the
main switch is on.
NOTICE
ECA15432
The accessory connected to the
auxiliary DC jack should not be used
with the engine turned off, and the
load must never exceed 12 W (1.0 A),
otherwise the fuse may blow or the
battery may discharge.
To use the auxiliary DC jack
1. Turn the main switch off.
2. Remove the auxiliary DC jack cap.
1. Luggage strap holder
1
1. Auxiliary DC jack cap
1
B67-9-13.book 26 ページ ２０１９年７月１９日 金曜日 午後２時５６分

Yamaha MT-10 2020 Specifications

General

Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel Injection
Transmission	6-speed
Front Suspension	43mm inverted fork, fully adjustable
Front Brakes	Dual 320mm hydraulic disc, ABS
Rear Brakes	220mm hydraulic disc, ABS
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Seat Height	825 mm
Starter System	Electric
Final Drive	Chain
Width	800 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Fuel Capacity	17 liters
Horsepower	160 HP
Maximum Power	160 HP @ 11500 rpm
Maximum Torque	111 Nm @ 9000 rpm
Length	2, 095 mm
Height	1110 mm
Wheelbase	1, 405 mm
Torque	111 Nm
