Yamaha MT-10 2020 User Manual

Instrument and control functions
5-19
1
2
3
4
5
6
7
8
9
10
11
12
knocking (or pinging) occurs, use a
gasoline of a different brand. Use of un-
leaded fuel will extend spark plug life
and reduce maintenance costs.
Gasohol
There are two types of gasohol: gaso-
hol containing ethanol and that contain-
ing methanol. Gasohol containing
ethanol can be used if the ethanol con-
tent does not exceed 10% (E10). Gas-
ohol containing methanol is not
recommended by Yamaha because it
can cause damage to the fuel system
or vehicle performance problems.
EAU74211
Fuel tank breather hose and
overflow hose
The breather hose prevents a vacuum
condition from forming within the fuel
tank.
The overflow hose drains excess gaso-
line and directs it safely away from the
vehicle.
Before operating the motorcycle:
 check each hose connection.
 check each hose for damage.
 confirm the end of each hose is not
blocked.
 confirm each hose is properly rout-
ed through its clamp(s).
For U49 models
For California
1. Clamp
2. Fuel tank breather hose
3. Fuel tank overflow hose
1. Clamp
2. Fuel tank overflow hose
1
3
2
1
2
B67-9-13.book 19 ページ ２０１９年７月１９日 金曜日 午後２時５６分

Yamaha MT-10 2020 Specifications

General

Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel Injection
Transmission	6-speed
Front Suspension	43mm inverted fork, fully adjustable
Front Brakes	Dual 320mm hydraulic disc, ABS
Rear Brakes	220mm hydraulic disc, ABS
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Seat Height	825 mm
Starter System	Electric
Final Drive	Chain
Width	800 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Fuel Capacity	17 liters
Horsepower	160 HP
Maximum Power	160 HP @ 11500 rpm
Maximum Torque	111 Nm @ 9000 rpm
Length	2, 095 mm
Height	1110 mm
Wheelbase	1, 405 mm
Torque	111 Nm
