Yamaha MT-10 SP User Manual

3-1
1
2
3
4
5
6
7
8
9
10
11
12
13
Description
EAU10411
Left view
1
6
2, 3 4 5
789
1. Headlight (page 8-34)
2. ERS coupler (page 5-34)
3. Spring preload adjuster (page 5-34)
4. Battery (page 8-30)
5. Fuses (page 8-31)
6. Spring preload adjuster (page 5-35)
7. Shift pedal (page 5-27)
8. Engine oil level check window (page 8-10)
9. Engine oil filter cartridge (page 8-10)
BGG-9-10-E0.book 1 ページ ２０２２年１月２６日 水曜日 午前１１時３７分

Yamaha MT-10 SP Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/55ZR17M/C (75W)
Wheelbase	1, 405 mm
Seat Height	835 mm
Length	2, 095 mm
Width	800 mm
Minimum Ground Clearance	135 mm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Front Brakes	Dual 320 mm hydraulic disc, ABS
Rear Brakes	220 mm hydraulic disc, ABS
Fuel Capacity	17 liters
