Yamaha MT-10 SP User Manual

Instrument and control functions
5-39
1
2
3
4
5
6
7
8
9
10
11
12
13
EAU57952
Ignition circuit cut-off system
This system prevents in-gear engine
starts unless the clutch lever is pulled
and the sidestand is up. Also, it will stop
the running engine should the sides-
tand be lowered while the transmission
is in gear.
Periodically check this system via the
following procedure.
TIP
 This check is most reliable if per-
formed with a warmed-up engine.
 See pages 5-1 and 5-2 for switch
operation information.
BGG-9-10-E0.book 39 ページ ２０２２年１月２６日 水曜日 午前１１時３７分

Yamaha MT-10 SP Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/55ZR17M/C (75W)
Wheelbase	1, 405 mm
Seat Height	835 mm
Length	2, 095 mm
Width	800 mm
Minimum Ground Clearance	135 mm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Front Brakes	Dual 320 mm hydraulic disc, ABS
Rear Brakes	220 mm hydraulic disc, ABS
Fuel Capacity	17 liters
