Yamaha MT-10 SP User Manual

Instrument and control functions
5-37
1
2
3
4
5
6
7
8
9
10
11
12
13
EAU84680
Luggage strap holders
Use the indicated strap points to secure
luggage ties to the vehicle.
EAU67050
EXUP system
This model is equipped with Yamaha’s
EXUP (EXhaust Ultimate Power valve)
system. This system boosts engine
power by means of a valve that controls
exhaust flow within the exhaust cham-
ber.
NOTICE
ECA15611
The EXUP system has been set and
extensively tested at the Yamaha
factory. Changing these settings
without sufficient technical knowl-
edge may result in poor perfor-
mance of or damage to the engine.
EAU93890
Power outlet
A 12-V accessory connected to the
power outlet can be used when the
main switch is on.
NOTICE
ECA27360
The accessory connected to the
power outlet should not be used
with the engine turned off, and the
load must never exceed 12 W (1.0 A),
otherwise the fuse may blow or the
battery may discharge.
To use the power outlet
1. Turn the main switch off.
2. Remove the power outlet cap.
1. Luggage strap holder
111
1. Power outlet cap
111
BGG-9-10-E0.book 37 ページ ２０２２年１月２６日 水曜日 午前１１時３７分

Yamaha MT-10 SP Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Fuel System	Fuel injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/55ZR17M/C (75W)
Wheelbase	1, 405 mm
Seat Height	835 mm
Length	2, 095 mm
Width	800 mm
Minimum Ground Clearance	135 mm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Front Brakes	Dual 320 mm hydraulic disc, ABS
Rear Brakes	220 mm hydraulic disc, ABS
Fuel Capacity	17 liters
