Yamaha RX-V357 Service Manual

RX-V357/HTR-5830
45
A
1
2
3
4
5
6
7
BCDEFGH I J
VRA
PSW
CKFD
CEFD
ADKEY0
VP
+5M
VRB
REM1
/BLK
DTFD
ADKEY1
+5MS
MG
DSP
AC4
NC
AC4
FUNCTION (4)
E
+5M
PSW
FUNCTION (5)
FUNCTION (2) P. C. B. (Side A)
EON FREQ/TEXT
START MODE
TUNING MODE
AUTO/MAN'L MONO
MEMORY
MAN'L/AUTO FM
6CH INPUT
INPUT
SPEAKERS
A/B/OFF
TONE
CONTROL
-
STEREO
EFFECT
PRESET/TUNING
EDIT
+
PROGRAM
INPUT MODE
FM/AM
A/B/C/D/E
NEXT
-+
VOLUME
PTYSEEK
BASS/TREBLE
PRESET/TUNING
SET MENU
FUNCTION (2) P. C. B. (Side B) Lead Free Solder Used
164
32
16
17
49
48
33
Ref. no. Location
D551 H5
D552 H5
IC551 F5
Q551 E5
Q552 F5
Q553 G5
Q554 G5
Q555 G5
Q556 F5
• Semiconductor Location
CB653
CB671
CB804
B, G, E models only
■ PRINTEDCIRCUITBOARD(Foilside)

Yamaha RX-V357 Specifications

General

Signal-To-Noise Ratio	100 dB
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	40
Frequency Response	10Hz - 100kHz
Outputs	1 x headphones, 1 x subwoofer output
Input Impedance	47 kohms
Audio D/A Converter	24-bit / 192kHz
Built-in Decoders	Dolby Digital, DTS
Surround Sound Effects	Dolby Pro Logic II
Sound Effects	Cinema DSP
Tuning Range	AM: 530 - 1710 kHz, FM: 87.5 - 108 MHz
Power Output	100 Watt
