Yamaha RX-V357 Service Manual

61
RX-V357/HTR-5830
RX-V357/HTR-5830
C486 UR837100 C.EL 10uF16V
C487 UR837100 C.EL 10uF16V
C488 UR866220 C.EL 2.2uF50V
C489 UR837100 C.EL 10uF16V
C490 UR837100 C.EL 10uF16V
C491 UR837100 C.EL 10uF16V
C492 UR837100 C.EL 10uF16V
C493 UR837100 C.EL 10uF16V
C494 UR837100 C.EL 10uF16V
C495 UR837100 C.EL 10uF16V
C496 UR837100 C.EL 10uF16V
C497 UR837100 C.EL 10uF16V
C498 UA654470 C.MYLAR 0.047uF50V
C499 UA652100 C.MYLAR 100pF50V
C500 UR838100 C.EL 100uF16V
C501 UR838100 C.EL 100uF16V
C502 UA652100 C.MYLAR 100pF50V
C503 UA652100 C.MYLAR 100pF50V
C504 UA652100 C.MYLAR 100pF50V
C505 UA652100 C.MYLAR 100pF50V
C506 UA652100 C.MYLAR 100pF50V
C507 UA653390 C.MYLAR 3900pF50V
C508 UR837100 C.EL 10uF16V
C509 UR837100 C.EL 10uF16V
C510 UR837100 C.EL 10uF16V
C511 UA652100 C.MYLAR 100pF50V
C512 UA652100 C.MYLAR 100pF50V
C513 UR837100 C.EL 10uF16V
C514 UR837100 C.EL 10uF16V
C515 UR837100 C.EL 10uF16V
C516 UR837100 C.EL 10uF16V
C517 UR837100 C.EL 10uF16V
C518 UR837100 C.EL 10uF16V
C519 UA654270 C.MYLAR 0.027uF50V
C520 UA654270 C.MYLAR 0.027uF50V
C521 UR838100 C.EL 100uF16V
C522 UR838100 C.EL 100uF16V
C523 UA654270 C.MYLAR 0.027uF50V
C524 UA654270 C.MYLAR 0.027uF50V
C525 UR837100 C.EL 10uF16V
C526 UR837100 C.EL 10uF16V
C527 UA652820 C.MYLAR 820pF50V
C528 UA652820 C.MYLAR 820pF50V
C529 UA652820 C.MYLAR 820pF50V
C530 UA652820 C.MYLAR 820pF50V
C531 UA652820 C.MYLAR 820pF50V
C554 UR837100 C.EL 10uF16V
C562 UR818330 C.EL 330uF6.3V
C612 UA652470 C.MYLAR 470pF50V
C614 UA652220 C.MYLAR 220pF50V
C615 UA652220 C.MYLAR 220pF50V
C616 UA652220 C.MYLAR 220pF50V
C617 UA652220 C.MYLAR 220pF50V
C618 UA652220 C.MYLAR 220pF50V
C619 UA652220 C.MYLAR 220pF50V
C620 UA652220 C.MYLAR 220pF50V
C621 UA652220 C.MYLAR 220pF50V
C622 FG651470 C.CE 47pF50V
C623 FG651470 C.CE 47pF50V
C624 UR837100 C.EL 10uF16V
C625 UR837100 C.EL 10uF16V
C626 UA654100 C.MYLAR 0.01uF50V
C651 UR837470 C.EL 47uF16V
C652 UR837470 C.EL 47uF16V
C653 UR837470 C.EL 47uF16V
C654 UR837470 C.EL 47uF16V
C655 UR838100 C.EL 100uF16V
C656 UR838100 C.EL 100uF16V
C657 UR867100 C.EL 10uF50V
C658 UR867100 C.EL 10uF50V
C659 UR838100 C.EL 100uF16V
C660 UA654100 C.MYLAR 0.01uF50V
C661 UR867100 C.EL 10uF50V
s C662 UR73A100 C.EL 10000uF16V
s C663 UR759220 C.EL 2200uF35V
s C664 UR759100 C.EL 1000uF35V
C665 VE326000 C.MYLAR.ML 0.1uF50V
C666 VE326000 C.MYLAR.ML 0.1uF50V
C667 VE326000 C.MYLAR.ML 0.1uF50V
C668 VE326000 C.MYLAR.ML 0.1uF50V
C669 VE326000 C.MYLAR.ML 0.1uF50V
D431 VU172500 DIODE.ZENR UDZS9.1B
D432 VT332900 DIODE 1SS355
D433 VT332900 DIODE 1SS355
D451 VU994300 DIODE.ZENR MA8075‑H7.7V
D452 VU994300 DIODE.ZENR MA8075‑H7.7V
D551 VU172100 DIODE.ZENR UDZS6.2B6.2V
D552 VU172100 DIODE.ZENR UDZS6.2B6.2V
D651 VU172000 DIODE.ZENR UDZS5.6BTE‑175.6V
D652 VU172000 DIODE.ZENR UDZS5.6BTE‑175.6V
s D653 WA653100 DIODE.BRG KBP103G1.0A200V
s D654 WA653100 DIODE.BRG KBP103G1.0A200V
* IC451 X6299A00 IC BD3816K1‑C
IC452 X3505A00 IC NJM2068MD‑TE2
IC453 X3505A00 IC NJM2068MD‑TE2
IC454 X3505A00 IC NJM2068MD‑TE2
IC455 X3505A00 IC NJM2068MD‑TE2
IC456 X3505A00 IC NJM2068MD‑TE2
IC551 X2874A00 IC M66003‑0101FPFLD
s IC651 X4153A00 IC KIA7812PI
s IC652 X4154A00 IC KIA7912PI
s IC653 X4928A00 IC KIA7805API5V
JK431 V9408200 JACK.PHONE MSJ‑064‑05BGR
PJ451 V7190400 JACK.PIN 6P
PJ452 V7046800 JACK.PIN 6PMSP‑246V1‑01NI
PJ611 V7189700 JACK.PIN 1P
P.C.B. FUNCTION
P.C.B. FUNCTION
Schm
Ref. PARTNO. Description
Markets
✻ New Parts
Schm
Ref. PARTNO. Description
Markets
✻ New Parts

Yamaha RX-V357 Specifications

General

Signal-To-Noise Ratio	100 dB
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	40
Frequency Response	10Hz - 100kHz
Outputs	1 x headphones, 1 x subwoofer output
Input Impedance	47 kohms
Audio D/A Converter	24-bit / 192kHz
Built-in Decoders	Dolby Digital, DTS
Surround Sound Effects	Dolby Pro Logic II
Sound Effects	Cinema DSP
Tuning Range	AM: 530 - 1710 kHz, FM: 87.5 - 108 MHz
Power Output	100 Watt
