Yamaha RX-V357 Service Manual

60
RX-V357/HTR-5830
RX-V357/HTR-5830
* WD044200 P.C.B. DSP(YEM) UCRKABGEL
* WE741100 P.C.B. DSP T
CB802 VQ961200 CN.BS.PIN 9P
CB803 VQ044500 CN.BS.PIN 11P
CB804 VF982200 CN.BS.PIN 14P
CB805 VQ961700 CN.BS.PIN 14P
C805 UR847220 C.EL 22uF25V
C816 UR819100 C.EL 1000uF6.3V
C822 UR829100 C.EL 1000uF10V
C824 UR819100 C.EL 1000uF6.3V
C827 UR818100 C.EL 100uF6.3V
C828 UR819100 C.EL 1000uF6.3V
C833 UR818470 C.EL 470uF6.3V
C834 UR818100 C.EL 100uF6.3V
C840 UR818470 C.EL 470uF6.3V
C859 UR818100 C.EL 100uF6.3V
C872 UR818100 C.EL 100uF6.3V
C883 UR818100 C.EL 100uF6.3V
C886 UR819100 C.EL 1000uF6.3V
C891 UR819100 C.EL 1000uF6.3V
C912 UR818100 C.EL 100uF6.3V
C913 UR818100 C.EL 100uF6.3V
C916 UR828100 C.EL 100uF10V
C918 UR866220 C.EL 2.2uF50V
C919 UR847100 C.EL 10uF25V
C920 UR847100 C.EL 10uF25V
D801 VT332900 DIODE 1SS355
D802 VT332900 DIODE 1SS355
D803 VT332900 DIODE 1SS355
D804 VT332900 DIODE 1SS355
D805 VT332900 DIODE 1SS355
D806 VT332900 DIODE 1SS355
D807 WB081800 DIODE SB01‑05Q
D808 WB081800 DIODE SB01‑05Q
D809 WB081800 DIODE SB01‑05Q
D810 WB081800 DIODE SB01‑05Q
IC801 X0238B00 IC YSS938
IC802 XV077B00 IC MSM514260E‑60JS
IC803 X3807A00 IC AK4628VQ
IC804 XZ003A00 IC PQ025EZ5MZP2.5V
IC805 X6051A00 IC UPC29M33T‑E1‑AZ
IC806 XZ012A00 IC TC74HCT08AF(EL)
IC807 XY070A00 IC MM74HCU04SJXINVER
PJ801 V4483900 JACK.PIN 1PYKC21‑3895
R807 HV753220 R.CAR.FP 2.2Ω1/4W
R892 HV753220 R.CAR.FP 2.2Ω1/4W
R902 HV753100 R.CAR.FP 1Ω1/4W
R903 HV753100 R.CAR.FP 1Ω1/4W
R910 VU224000 R.MTL.FLM 0.22Ω1W
R919 RE045100 R.ARRAY 100Ωx4
R920 RE045100 R.ARRAY 100Ωx4
R921 RE045100 R.ARRAY 100Ωx4
R922 RE045100 R.ARRAY 100Ωx4
U801 WB001400 CN.PHOT.SN 1PGP1FA553RZ
U802 WB001400 CN.PHOT.SN 1PGP1FA553RZ
XL801 V3625700 RSNR.CRYS 24.576MHz
* WE545000 P.C.B. FUNCTION UCTKA
* WE545100 P.C.B. FUNCTION R
* WE545200 P.C.B. FUNCTION BGE
* WE857100 P.C.B. FUNCTION(YEM) L
CB431 VK026300 CN.BS.PIN 4P
CB451 VQ963900 CN.BS.PIN 18P
CB452 VQ961500 CN.BS.PIN 12P
CB453 VM859500 CN.BS.PIN 11P
CB454 VQ961200 CN.BS.PIN 9P
CB551 VN394900 CN.BS.PIN 14P
CB611 VQ962100 CN.BS.PIN 18P
CB652 LB919090 CN.BS.PIN 9P
CB653 VK024700 CN.BS.PIN 3P
CB676 VQ963900 CN.BS.PIN 18P
CB677 VQ962100 CN.BS.PIN 18P
CB691 V9377900 CN.BS.PIN 4PSEVHSERIES RL
C431 UA654100 C.MYLAR 0.01uF50V
C432 UA654100 C.MYLAR 0.01uF50V
C433 UA654100 C.MYLAR 0.01uF50V
C434 UA654100 C.MYLAR 0.01uF50V
C457 UA652220 C.MYLAR 220pF50V
C458 UA652220 C.MYLAR 220pF50V
C459 UA652220 C.MYLAR 220pF50V
C460 UA652220 C.MYLAR 220pF50V
C461 FG651470 C.CE 47pF50V
C462 FG651470 C.CE 47pF50V
C463 UR837100 C.EL 10uF16V
C464 UR837100 C.EL 10uF16V
C465 UR837100 C.EL 10uF16V
C466 UR837100 C.EL 10uF16V
C467 UR847470 C.EL 47uF25V
C468 UR847470 C.EL 47uF25V
C469 UR838100 C.EL 100uF16V
C470 UR838100 C.EL 100uF16V
C473 UR837100 C.EL 10uF16V
C474 UR837100 C.EL 10uF16V
C475 UR837100 C.EL 10uF16V
C476 UR837100 C.EL 10uF16V
C477 UR837100 C.EL 10uF16V
C478 UR837100 C.EL 10uF16V
C479 UR837100 C.EL 10uF16V
C480 UA653470 C.MYLAR 4700pF50V
C481 VE326000 C.MYLAR.ML 0.1uF50V
C482 VE326000 C.MYLAR.ML 0.1uF50V
C483 UA653470 C.MYLAR 4700pF50V
C484 VE326000 C.MYLAR.ML 0.1uF50V
C485 VE326000 C.MYLAR.ML 0.1uF50V
P.C.B. DSP & P.C.B. FUNCTION
P.C.B. DSP
Schm
Ref. PARTNO. Description
Markets
✻ New Parts
Schm
Ref. PARTNO. Description
Markets
✻ New Parts

Yamaha RX-V357 Specifications

General

Signal-To-Noise Ratio	100 dB
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	40
Frequency Response	10Hz - 100kHz
Outputs	1 x headphones, 1 x subwoofer output
Input Impedance	47 kohms
Audio D/A Converter	24-bit / 192kHz
Built-in Decoders	Dolby Digital, DTS
Surround Sound Effects	Dolby Pro Logic II
Sound Effects	Cinema DSP
Tuning Range	AM: 530 - 1710 kHz, FM: 87.5 - 108 MHz
Power Output	100 Watt
