3-8
Outboard Rigging Guide - 2001
SWITCH PANEL ASSEMBLIES
For switch panel part numbers and descrip-
tions, refer to the chart on the following pages.
Single
• The single panel assembly is for use with any
remote control except the 703 standard side
mount control box. Yamaha makes available
single panels that vary in function and model
application.
• T9.9E - This switch panel features the igni-
tion switch, emergency stop lanyard, and an
oil pressure light.
• 9.9 ~ 30HP - There are two panels available
with the same function, but different configu-
ration. Both panels feature the ignition
switch, emergency stop lanyard, choke con-
trol.
• F30 ~ F115, 40 ~ 90, 9.9 ~ 200HP, C40T ~
C90 - The panel features the ignition switch,
emergency stop lanyard, choke control, and
warning horn.
Dual Engine Systems
• The panel assembly is used on dual engine
systems. All feature a unified emergency stop
lanyard, two ignition switches, and a warning
buzzer.
NOTE: Do not use a dual switch panel with the
40~90HP, LF115 or C40T~C90 models. The
overheat and low oil warning system on these
panels are not compatible with these models.
Accessory Panels
Yamaha offers three accessory panels.
• Oil warning light panel for the T9.9ELR
• Single ignition key switch with push-for
choke activation
• Emergency stop lanyard panel - single
SWITCH PANELS
Push to Choke Main Switch with Warning Horn
704-82570-06-00 Single Main Switch w/Stop Switch on Panel
6K1-82570-05-00 Dual Main Switch w/Single Stop Switch on Panel
64D-82570-02-00 Single Main Switch Only (Small Square Panel)
64D-82570-10-00 Single Stop Switch Only (Small Square Panel)
689-82570-18-00 Single Main Switch w/Stop Switch on Panel (No Horn for Small Models)
Standard Main Switch with Oil Pressure Light, No Choke, No Warning Horn
6G8-82570-02-00 Single Main Switch, Oil Light and Stop Switch on Panel (F9.9/T9.9)
6G8-83530-00-00 Oil Light on Panel Only - Used with 703 Control (F9.9/T9.9)
