6-41
60, C60/C70/70 Tiller Handle & Steering Friction Kit [Cont’d.]
REF
NO PART NUMBER DESCRIPTION QTY.
1 6H3-W0086-Z0-4D Handle Steering Ass’y1
2 63D-42111-01-4D Handle, Steering 1
3 664-42119-00-00 Grip, Steering Handle 1
4 6G1-42177-00-00 Rubber, Handle 1
5 6H2-42137-00-00 Indicator, Throttle 1
6 90269-02M09-00 Rivet 1
7 90149-05M13-00 Screw 1
8 92990-10600-00 Washer, Plate 1
9 90501-23215-00 Spring, Compression 1
10 90386-08032-00 Bush 1
11 6H3-26301-00-00 Throttle Cable Ass’y1
12 63D-42121-10-4D Bracket 1
13 90101-12M09-00 Bolt 1
14 92990-12200-00 Washer, Plain 1
15 90386-12M93-00 Bush 2
16 90206-12M22-00 Washer, Wave 1
17 90185-12058-00 Nut, Self-locking 1
18 6G8-44191-00-00 Indicator, Shift 1
19 63D-44159-01-00 Handle, Gear Shift 1
20 63D-44100-11-00 Shift Link Ass’y1
21 63D-44104-00-00 • Plate Comp. 1
22 63D-48261-00-00 • Arm, Throttle 1
23 63D-42115-00-00 • Shaft, Steering Handle 1
24 650-42152-00-94 • • Gear 1
25 91690-30025-00 • • Pin, Spring 1
26 63D-42159-00-00 • • Stay 1
27 98580-06016-00 • Screw, Pan Head 1
28 93430-08006-00 • Circlip 1
29 63D-44113-00-00 • Cam Plate, Handle 1
30 63D-48236-00-00 • Roller, Detent 1
31 63D-48119-00-00 • Cover 1
32 63D-42153-00-00 • Shaft, Throttle Control 1
33 63D-44132-00-00 • Bushing 1
34 63D-48118-00-00 • Clip, Shift Lever 1
35 63D-48237-00-00 • Adaptor 1
36 98785-05014-00 • Screw, Flat Head 2
37 63D-48238-00-00 • Spring, Detent 1
38 63D-42181-00-00 • Washer 2
39 97095-06016-00 Bolt 4
40 92995-06600-00 Washer 4
41 63D-42725-00-00 Grommet 1
42 63D-44173-00-00 Lever, Shfit Control 1
43 90159-06M18-00 Screw, With Washer 2
44 97095-08040-00 Bolt 1
45 92995-08600-00 Washer 1
46 6H3-48321-01-00 Cable 1
47 90386-29M95-00 Bush 1
48 90202-24M53-00 Washer, Plate 1
49 63D-48531-00-00 Bracket, Remote Control 1 1
50 63D-48538-00-00 Clamp, Cable 1 2
51 97095-06016-00 Bolt 2
52 92995-06600-00 Washer 2
53 90387-12M02-00 Collar 1
54 92990-12600-00 Washer, Plate 1
55 63D-42126-00-00 Friction, Steering Handle
Grip 1
56 63D-48154-00-00 Knob, Throttle 1
57 95380-06600-00 Nut 1
58 91490-20010-00 Pin, Cotter 1
59 90464-09M42-00 Clamp 1
• Component parts
REF
NO PART NUMBER DESCRIPTION QTY.
60 93430-04M03-00 Circlip 2
61 63D-42131-10-00 Cover, Handle Steering 1
62 90480-14M14-00 Grommet 1
63 97885-06016-00 Screw, Pan Head 4
64 92995-06600-00 Washer 4
65 97885-06040-00 Screw, Pan Head 3
66 92995-06600-00 Washer 3
67 663-42518-00-00 Shaft, Friction 1
68 663-42528-00-00 Plate, Friction 1
69 97080-06035-00 Bolt 1
70 90175-06003-00 Nut, Wing 1
71 692-42515-01-00 Rod, Steering 1
72 92990-08600-00 Washer, Plate 2
73 90185-08057-00 Nut, Self-locking 2
74 63D-44114-00-00 Stopper 1
75 6H5-82510-00-00 Main Switch Ass’y1
76 63D-82575-00-00 Engine Stop Switch Ass’y. 1
77 682-82556-00-00 • Stopper 1
78 689-8257Y-00-00 • Cap 1
79 6H3-82540-00-00 Neutral Switch Ass’y1
80 6H3-82554-00-00 Stay, Neutral Switch 1
81 663-82555-01-00 Damper, Main Switch 1
82 97885-06012-00 Screw, Pan Head 1
83 63D-8252E-01-4D Cover, Main Switch 1
84 63D-8252F-01-4D Cover, Main Switch 1
85 97885-06025-00 Screw, Pan Head 1
86 92995-06100-00 Washer, Spring 1
87 97095-06025-00 Bolt 1
88 92995-06100-00 Washer, Spring 1
89 97095-06020-00 Bolt 1
90 92995-06100-00 Washer, Spring 1
91 90167-06M00-00 Screw, Tapping 2
92 92990-06200-00 Washer 2
93 6H2-82586-01-00 Extension, Wire Harness 1
94 90465-13M36-00 Clamp 1
Outboard Rigging Guide - 2001
60, C60/C70/70 Tiller Handle &
Steering Friction Kit
