3.3 Main Circuit Wiring
3-7
3.3.2 SERVOPACK Main Circuit Cable
Use the following cables for main circuit of the SERVOPACK. Contact your
Yaskawa representative for details.
If you make cables by yourself, read the following items.
Cable
Terminal
Symbols
SERVOPACK Model: SGDV-
1R7E 2R9E
For power supply
L1, L2, C1,
C2,
JZSP-CF1G00--E
For servomotor
main circuit
U, V,
W,
JZSP-CF1M00--E
(For servomotors without brakes)
JZSP-CF1M10--E
(For servomotors with brakes)
JZSP-CF1M20--E
(For servomotors without brakes, flexible type)
JZSP-CF1M30--E
(For servomotors with brakes, flexible type)
• Wire sizes are selected for three cables per bundle at 40°C sur-
rounding air temperature with the rated current.
• Use the withstand voltage wires (for 100 V or more)
• Use the wires whose outside diameter of insulator is 1.85 mm or
less.
• If cables are bundled in PVC or metal ducts, take into account the
reduction of the allowable current.
• Use a heat-resistant wire under high surrounding air or panel
temperatures.
• The length of cables for power supply is 10 m max., and the
length of cables for servomotor main circuit is 50 m max.
Cable
SERVOPACK Model: SGDV-
Remarks
1R7E 2R9E
CN3 for
power
supply
Connector
43025-0600
*
6 poles
Contact
43030-0001
*
–
For main circuit
power supply
(L1, L2, )
UL1007, AWG20
Rated voltage
300 V,
Rated temperature
80°C
For control circuit
power supply
(C1, C2, )
UL1007, AWG20
Rated voltage
300 V,
Rated temperature
80°C
∗ Made by Molex Japan LLC.
