36
YORK INTERNATIONAL
FORM 201.19-NM6 (804)
Installation
50 Hz Models:
PHOTOGRAPH OF
50 HZ MODEL LOGIC SECTION
FIG. 11 – LOGIC SECTION LAYOUT
LOGIC SECTION LAYOUT
00247VIP
ITEM
1
2
3
4
5
6
7
8
DESCRIPTION
Microprocessor Board
I/O Board #2
I/O Expansion Board #1
Power Supply Board
Relay Output Board #1
Relay Output Board #2
Flow Switch & Customer Connection Terminals
Circuit Breakers CB1 - CB5
1
2
7
3
4
5
6
8
