York YCAS - Operating Limitations and Sound Power Data

49
YORK INTERNATIONAL
FORM 201.19-NM6 (804)
7
OPERATING LIMITATIONS AND SOUND POWER DATA
OPERATING LIMITATIONS – SI UNITS
* Maximum Ambient w/ High Ambient Kit is 54°C.
MIN MAX
LEAVING CHILLED LIQUID TEMP ( °C) 4.5 15
CHILLED WATER TEMP DIFFERENCE ( °C) 3 10
WATER SIDE PRESSURE (BAR) – 10
REFRIGERANT SIDE PRESSURE (BAR) – 20
LIQUID FLOW
MODEL LITERS/SECOND
YCAS MIN. MAX.
0693EC 14 50.0
0773EC 14 50.0
0783EC 14 50.0
0873EC 16 50.0
0953EC 16 50.0
1063EC 19 67.0
1093EC 21 67.0
1163EC 21 67.0
1263EC 21 67.0
AIR STANDARD FANS –18 46
ENTERING HIGH PRESS. FANS –18 46
CONDENSER (°C) LOW NOISE FANS –18 46
FAN STANDARD FANS 20
AVAILABLE STATIC HIGH PRESS. FANS OPTION 1 85
PRESSURE (Pa) HIGH PRESS. FANS OPTION 2 150
LOW NOISE FANS 10
200
230
ELECTRICAL THREE PHASE 60 Hz (V) 380
460
575
SOUND DATA (DBA)
MODEL
STD FAN
6-POLE
MOTOR
LOW NOISE
FAN
8-POLE
MOTOR
LOW NOISE FAN
8-POLE MOTOR
W/COMPRESSOR
BLANKET
LOW NOISE FAN
8-POLE MOTOR
W/ PERIMETER KIT
(DISCHARGE LINE WRAPPED)
LOW NOISE FAN
8-POLE MOTOR
W/COMPRESSOR
BLANKET & PERIMETER KIT
(DISCHARGE LINE WRAPPED)
0693EC 107 105 104 100 99
0773EC 108 106 105 101 100
0783EC 108 106 105 102 101
0873EC 108 106 105 103 102
0953EC 109 107 106 102 101
1063EC 110 108 107 102 101
1093SC 1-0 107 106 103 102
1163EC 110 108 107 103 102
1263EC 110 108 107 103 102
