127YORK INTERNATIONAL
FORM 201.18-NM1 (102)
Summary of Settings
The following table gives a summary of Modes (dis-
played messages) which can be selected using the Open
and Closed positions for each of the eight SW1 Dip
Switches.
SWITCH
SWITCH “OPEN” SWITCH “CLOSED”
SETTING SETTING
1 Water Cooling Brine Cooling
2
Standard Ambient Low Ambient
Control Control
3 Refrigerant R-407C Refrigerant R-22
4 Spare Spare
5 Spare Spare
6 Spare Spare
7 Spare Spare
8 Spare Spare
3.8 FUNCTION KEY
Pressing the Function key only displays the same mes-
sage as pressing the Status key. Pressing the Function
key followed by another display key will scroll through
all the data available under that key once. E.g., pressing
the Function key followed by the System 1 Data key will
result in scrolling through the 5 displays shown in Sec-
tion 3.3 without the need to press the System 1 Data key
to scroll to the next display. After scrolling through the
data, the display returns to the status message.
The following keys can be scrolled using the Function
Key: Chilled Liquid Temps, System # Data, Motor Cur-
rent and Options.
8
