JOHNSON CONTROLS
286
FORM 201.23-NM2
ISSUE DATE: 09/25/2020
SECTION 8 - MICROPANEL
TABLE 25 - ANALOG INPUT CONNECTIONS (CONT'D)
BOARD HEADER ANALOG INPUT
Chiller Control Board J20-2 Comp 3 Motor Temperature 2
Chiller Control Board J20-3 Comp 3 Motor Temperature 3
Chiller Control Board J20-6 Comp 4 Motor Temperature 1
Chiller Control Board J20-7 Comp 4 Motor Temperature 2
Chiller Control Board J20-8 Comp 4 Motor Temperature
Chiller Control Board J23-13 Sys 3 Suction Temperature
Chiller Control Board J23-3 Sys 3 Oil Temperature
Chiller Control Board J23-16 Sys 3 Discharge Temperature
Chiller Control Board J23-6 Sys 3 Flash Tank Level Sensor
Chiller Control Board J23-20 Sys 3 Suction Pressure
Chiller Control Board J23-22 Sys 3 Oil Temperature
Chiller Control Board J23-24 Sys 3 Discharge Pressure
Chiller Control Board J24-13 Sys 4 Suction Temperature
Chiller Control Board J24-3 Sys 4 Oil Temperature
Chiller Control Board J24-16 Sys 4 Discharge Temperature
Chiller Control Board J24-6 Sys 4 Flash Tank Level Sensor
Chiller Control Board J24-20 Sys 4 Suction Pressure
Chiller Control Board J24-22 Sys 4 Oil Pressure
Chiller Control Board J24-24 Sys 4 Discharge Pressure
VSD Logic Board J1-1 to J1-2 Comp 1 Phase A Motor Current
VSD Logic Board J1-3 to J3-4 Comp 1 Phase B Motor Current
VSD Logic Board J1-5 to J1-6 Comp 1 Phase C Motor Current
VSD Logic Board J1-13 to J1-14 Comp 3 Phase A Motor Current
VSD Logic Board J1-15 to J1-16 Comp 3 Phase B Motor Current
VSD Logic Board J1-17 to J1-18 Comp 3 Phase C Motor Current
VSD Logic Board J2-1 to J2-2 Comp 2 Phase A Motor Current
VSD Logic Board J2-3 to J2-4 Comp 2 Phase B Motor Current
VSD Logic Board J2-5 to J2-6 Comp 2 Phase C Motor Current
VSD Logic Board J2-9 to J2-10 Comp 4 Phase A Motor Current
VSD Logic Board J2-11 to J2-12 Comp 4 Phase B Motor Current
VSD Logic Board J2-13 to J2-14 Comp 4 Phase C Motor Current
VSD Logic Board J3-1 +DC Bus Voltage 1
VSD Logic Board J3-2 1/2 DC Bus Voltage 1
VSD Logic Board J3-3 -DC Bus Voltage 1
VSD Logic Board J3-4 -DC Bus Voltage 2
VSD Logic Board J3-5 1/2 DC Bus Voltage 2
VSD Logic Board J3-6 +DC Bus Voltage 2
VSD Logic Board J6-8 Comp 1 IGBT Baseplate Temperature
VSD Logic Board J7-8 Comp 3 IGBT Baseplate Temperature
VSD Logic Board J8-8 Comp 2 IGBT Baseplate temperature
VSD Logic Board J9-8 Comp 4 IGBT Baseplate Temperature
VSD Logic Board R19 Comp 1 Overload Adjust
VSD Logic Board R42 Comp 3 Overload Adjust
VSD Logic Board R64 Comp 2 Overload Adjust
VSD Logic Board R86 Comp 4 Overload Adjust
To Next Page
