JOHNSON CONTROLS
65
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 09/25/2020
6
PHYSICAL DATA (SI - HIGH EFFICIENCY) (CONT'D)
REFRIGERANT R-134a
HIGH EFFICIENCY
MODEL NUMBER (YCIV____ E/V)
GENERAL UNIT DATA 60 HZ 0267 0287 0327 0357
Number of Independent Refrigerant Circuits 3 3 3 3
Refrigerant Charge, R-134a, Ckt.-1/Ckt.-2, kg 84 / 84 / 77 84 / 84 / 105 84 / 84 / 105 105 / 105 / 105
Oil Charge, Ckt.-1/Ckt.-2, L 19 / 19 / 15 19 / 19 / 19 19 / 19 / 19 19 / 19 / 19
Glycol Charge (43% concentration), L 0 0 0 0
Compressors, Semihermetic Screw
Quantity per Chiller 3 3 3 3
Condensers, High Efficiency Fin/Tube with Integral Subcooler
Total Chiller Coil Face Area, m
2
38 44 44 49
Number of Rows 3 3 3 3
Fins per meter 669 669 669 669
Condenser Fans
Number, Ckt.-1/Ckt.-2 05/05/04 05/05/06 05/05/06 06/06/06
Low Noise Fans
Fan Motor, HP/kWi 2/1.50 2/1.50 2/1.50 2/1.50
Total Chiller Airow, L/s 85904 98176 98176 110448
Ultra Quiet Fans
Fan Motor, HP/kWi 2/1.50 2/1.50 2/1.50 2/1.50
Total Chiller Airow, L/s 85904 98176 98176 110448
Dual Speed Fans - Normal Speed
Fan, KWi 1.5 1.5 1.5 1.5
Total Chiller, m
3
/s 73 83 83 93
Dual Speed Fans - Lower Speed
Fan, KWi 1.5 1.5 1.5 1.5
Total Chiller, m
3
/s 56 63 63 71
High Static Fans
Fan, KWi 3.7 3.7 3.7 3.7
Total Chiller, m
3
/s 92 117 117 129
Evaporator, Direct Expansion
Water Volume, L 764.6 764.6 893.3 893.3
Maximum Water Side Pressure, bar 10 10 10 10
Maximum Refrigerant Side Pressure, bar 16 16 16 16
Minimum Chilled Water Flow Rate, L/s 16 16 19 19
Maximum Chilled Water Flow Rate, L/s 76 76 76 76
Water Connections, mm 245 245 245 245
