SECTION 6 - TECHNICAL DATA
STANDARD EFFICIENCY 2-COMPRESSOR UNITS
One Field Provided Power Supply Circuit. Field Connections to Factory provided
Terminal Block (Standard); or Individual System Breakers (Optional).
STANDARD EFFICIENCY YCIV_ _ _ _ S/P/H STANDARD EFFICIENCY YCIV_ _ _ _ S/P/H
MODEL NO./NAMEPLATE
SYSTEM 1
SYSTEM 2
STD. & ULTRA QUIET
COND. FANS
HIGH HEAD/STATIC
COND. FANS
TWO-SPEED
COND. FANS
STD. & ULTRA QUIET
COND. FANS
HIGH HEAD/STATIC
COND. FANS
TWO-SPEED
COND. FANS
YCIV
S/P/H
INPUT
VOLTS
(9)
INPUT
FREQ
COMPRESSOR
RLA (5)
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
RLA (5)
CONDENSER
FANS
COMPRESSOR
RLA (5)
CONDENSER
FANS
COMPRESSOR
RLA (5)
CONDENSER FANS
COMPRESSOR
RLA (5)
CONDENSER
FANS
QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
QTY.
FLA
(EA)
QTY.
FLA
(EA)
QTY.
FLA
(EA)
QTY.
FLA
(EA)
0157
460 60 120 4 2.8
120 4 2.8
380 60 152 4 3.5 152 4 9.3 152 4 3.5 152 4 9.3
0177
460 60 159 4 2.8
105 4 2.8
380 60 201 4 3.5 201 4 9.3 133 4 3.5 133 4 9.3
0187
460 60 162 5 2.8
120 4 2.8
380 60 205 5 3.5 205 5 9.3 152 4 3.5 152 4 9.3
0207
460 60 145 5 2.8
162 4 2.8
380 60 184 5 3.5 184 5 9.3 206 4 3.5 206 4 9.3
0227
460 60 162 5 2.8
162 5 2.8
380 60 205 5 3.5 205 5 9.3 205 5 3.5 205 5 9.3
0247
460 60 193 6 2.8
160 5 2.8
380 60 245 6 3.5 245 6 9.3 203 5 3.5 203 5 9.3
0267
460 60 191 6 2.8
191 6 2.8
380 60 242 6 3.5 242 6 9.3 242 6 3.5 242 6 9.3
YCIV S/P/H
CONTROL
KVA (7)
UNIT SHORT CIRCUIT
WITHSTAND (KA)
FIELD WIRING & PROTECTION
FIELD WIRING & PROTECTION
STD. & ULTRA QUIET COND. FANS HIGH HEAD/HIGH STATIC FANS TWO-SPEED COND. FANS
TERMINAL
BLOCK
(STD)
CIRCUIT
BREAKER
(OPT)
MINIMUM
CKT.
AMPACITY
(MCA) (3)
RECOMMENDED
FUSE/CKT.
BREAKER RAT-
ING (4)
MAX. IN-
VERSE TIME
CKT. BRKR.
RATING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
MINIMUM
CKT.
AMPACITY
(MCA) (3)
RECOMMENDED
FUSE/CKT.
BREAKER RAT-
ING (4)
MAX.
INVERSE
TIME CKT.
BRKR. RAT-
ING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
MINIMUM
CKT.
AMPACITY
(MCA) (3)
RECOMMENDED
FUSE/CKT.
BREAKER
RATING (4)
MAX.
INVERSE
TIME CKT.
BRKR. RAT-
ING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
0157
1.8 30 65 293 350 400 400
1.8 30 65 370 450 500 500
417 500 500 500
0177
1.8 30 65 326 400 450 450
1.8 30 65 413 500 600 600
459 600 600 600
0187
1.8 30 65 348 400 500 500
1.8 30 65 440 500 600 600
492 600 700 700
0207
1.8 30 65 373 450 500 500
1.8 30 65 472 600 600 600
525 600 700 700
0227
1.8 30 65 392 450 500 500
1.8 30 65 496 600 700 700
554 700 700 700
0247
1.8 30 65 433 500 600 600
1.8 30 65 547 700 700 700
610 700 800 800
0267
1.8 30 65 464 600 600 600
1.8 30 65 587 700 800 800
657 800 800 800
See page 92 for Electrical Data footnotes.
