Zte ZXHN H3600 User Manual

6 Configure the Local Network
Figure 6-27 Domain name
2. Type the domain name in the text box.
3. Click Apply button to apply the changes.
Configure the host name
1. Click Host name to open the Host Name page, see Figure 6-28.
Figure 6-28 Host Name
2. Type the host name in the Host Name text box and the IP address in the IP Ad-
dress text box.
3. Click Apply button to apply the changes.
6.10 Configure the Device Role
The section describes how to configure the device role in the mesh network.
 Controller: set the device as the main control AP in the mesh network and connects
the LAN interface of the optical cat.
 Agent: set the device as subordinate AP in the mesh network to connect the WAN in-
terface of the main control AP.
Steps
1. On the main page of the ZXHN H3600, select Local Network > NetSphere to the
NetSphere page, see Figure 6-29.
SJ-20201203151144-003 | 2021-06-16(R1.0) 71

Zte ZXHN H3600 Specifications

General

Category	Gateway
POTS Ports	2
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Model	ZXHN H3600
Wi-Fi Standard	IEEE 802.11b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Antenna Type	Internal
Security	WPA/WPA2, WEP
Device Type	GPON ONT
Antennas	4
GPON Interface	1 x GPON
Ethernet Ports	4 x GE
