Zte ZXHN H3600 User Manual

ZXHN H3600 Maintenance Management Guide
Table 7-3 Parameter Descriptions for the Echo Cancellation
Parameter Description
Echo Cancellation Whether to disable the echo cancellation feature.
3. Click Apply button to apply the changes.
7.4 Configure the SIP Protocol
This procedure describes how to configure the SIP Protocol.
Steps
1. On the main page of the ZXHN H3600 device, select VoIP > SIP Protocol to the SIP
Protocol page, see Figure 7-5.
Figure 7-5 SIP Protocol Page
2. Set the parameters. Table 7-4 describes the SIP protocol parameters.
Table 7-4 Description of the SIP Protocol Parameters
Parameter Description
Local Port Local port that the SIP protocol uses, default: 5060.
Primary Proxy Server IP address of the active SIP proxy server that the ISP provides, which
must be the same as that configured on the SIP server.
Primary Outbound Proxy
Server
IP address of the active outbound proxy server that the ISP provides,
which must be the same as that configured on the SIP server.
76 SJ-20201203151144-003 | 2021-06-16(R1.0)

Zte ZXHN H3600 Specifications

General

Category	Gateway
POTS Ports	2
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Model	ZXHN H3600
Wi-Fi Standard	IEEE 802.11b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Antenna Type	Internal
Security	WPA/WPA2, WEP
Device Type	GPON ONT
Antennas	4
GPON Interface	1 x GPON
Ethernet Ports	4 x GE
