Chapter10Cables
Device-end
Connectortype
Opposite-end
Connectortype
CableTypeCableUsage
LCLC
Single-mode
indooropticalber
Connectionbetweeninterfaceline
cards
LCSC
Multimodeindoor
opticalber
Connectionbetweeninterfaceline
cards
LCSC
Single-mode
indooropticalber
Connectionbetweenaninterfaceline
cardandothertypesofdevices
LCLC
Multimodeindoor
opticalber
Connectionbetweenaninterfaceline
cardandothertypesofdevices
InterfaceboardsoftheZXR10ZSRV2mainlyuseLC-typeconnectors,seeFigure10-8.
Figure10-8LC-typeFiberConnector
10.2.5SHDSLCables
AnSHDSLcableisaneight-coreCAT5e100-ohmnon-shieldedtwistedpaircable.One
endisconnectedtooneRJ45connector,andtheotherendisconnectedtofourRJ11
connectors.TheSHDSLcablescanbeusedfortransmittingmultipletypesofsignals,
includingvoice,data,andvideosignals.
ForanoverviewoftheSHDSLcable,seeFigure10-9.
Figure10-9SHDSLCable
1.RJ45connector2.Eight-coreCAT5e100-ohm
non-shieldedtwistedpair
cable
3.RJ11connector
10-9
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
