Chapter5ZXR102800-3EChassis
5.2PowerSupplies
ZXR10ZSRV2serialrouterssupportavoltagewithintherangeof100V–240V,ACpower
of50Hz–60Hz,andDCpowerfrom-38Vto-72V.The1+1dual-powerredundancymode
andpowersupplyswappingareavailable.
Thepowermoduleshavethefollowingfunctions:
lAlarmsaregeneratedduetoahighinputoroutputvoltage.
lAlarmsaregeneratedduetoahighoutputcurrent.
lAlarmsaregeneratedduetoahighorlowtemperature.
Caution!
TurnoffbothpowersuppliesbeforeinstallingandmaintainingtheZXR10ZSRV2.
5.2.1ACPowerModule
Panel
Figure5-5showsthepaneloftheACpowermoduleofaZXR102800-3Echassis.
Figure5-5PaneloftheACPowerModule
Indicators
ForfunctionsoftheindicatorsontheACpowermoduleoftheZXR102800-3Echassis,
refertoT able5-4.
Table5-4FunctionsoftheIndicatorsonthePaneloftheACPowerModuleofthe
ZXR102800-3EChassis
IndicatorNumberColorDescription
RUN1GreenThepowermoduleisoperatingproperly.
ALM1RedThepowermoduleisoperatingimproperly.
Buttons
ForfunctionsofthepowerbuttonsontheACpowermoduleoftheZXR102800-3Echassis,
refertoT able5-5.
5-5
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
