ZXR10ZSRV2HardwareDescription
9.22RAC-PIU-04GE-SFP
Overview
RAC-PIU-04GE-SFPboardprovidesthefollowingfunctions:
lProvidesfourGEopticalinterfaceswhichsupport1000BASE-X.
lSupportshotswapping.
lSupportsboardinformationqueryandtemperaturemonitoring.
Panel
ForthepaneloftheRAC-PIU-04GE-SFPboard,seeFigure9-22.
Figure9-22FrontPaneloftheRAC-PIU-04GE-SFPBoard
InterfaceProperties
TheRAC-PIU-04GE-SFPboardusesSFPopticalmodules.Foradescriptionofthe
interfaceproperties,refertoT able9-64.
Table9-64InterfacePropertiesoftheRAC-PIU-04GE-SFPBoard
PropertyDescription
ConnectortypeLC-typeSFPopticalmoduleinterface
OperationalmodeFullduplex
AppliedstandardIEEE802.3zGigabitEthernetstandard
SupportedlinkprotocolEthernetFrame
Supportednetwork
protocol
Ethernet
Indicators
ForadescriptionoftheindicatorsoftheRAC-PIU-04GE-SFPboard,refertoT able9-65.
Table9-65DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-04GE-SFPBoard
IndicatorColorDescription
RUNGreenTheindicatorislitwhentheboardisoperatingproperly.
ALMRedTheindicatorislitiftheboardproducesanalarm.
9-34
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
