ZXR10ZSRV2HardwareDescription
lSupportsseparationoftheforwardingplaneandcontrolplane.
Panel
ForthepaneloftheRAC-2838-MPFU-A,seeFigure7-1.
Figure7-1PaneloftheRAC-2838-MPFU-A
Interfaces
ForadescriptionoftheinterfacesoftheRAC-2838-MPFU-A,refertoT able7-1.
Table7-1DescriptionoftheInterfacesoftheRAC-2838-MPFU-A
InterfaceTypeSilkScreenNameDescription
Networkinterface
(RJ45)
OAMNetworkport(10M/100M/1000M)usedforsystem
maintenanceandprogramdownloading
CONSOLEDebuggingportforsystemmanagementand
conguration
Serialport(RJ45)
AUXDebuggingserialportofaPIUandModem
convergenceport
USB1 USBinterface
USB2
USB2.0interface,whichtransmitstheprogramdata
andotherdata
GEelectronic
interface
GE3–6FourGEelectronicinterfaces
COMBOinterfaceCOMBO1/2,GE1–2TwoCOMBOinterfaces
Indicators
ForadescriptionoftheLEDindicatorsonthepaneloftheRAC-2838-MPFU-A,referto
Table7-2.
Table7-2IndicatorDescriptionsfortheRAC-2838-MPFU-A
IndicatorNumberColorDescription
RUN1GreenTheindicatorislitwhentheboardisoperating
properly.
ALM1RedTheindicatorislitiftheboardisnotoperating
properly.
LINK/ACT2GreenLinkstateindicatorsofCOMBOinterfaces.
7-2
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
