Chapter9LineInterfaceBoards
ParameterDescription
Powerconsumption7W
Weight0.22lb.(0.1kg)
Rate1GE×4
9.7RAC-PIU-LTE
Overview
TheRAC-PIU-LTEisa3G/LTEinterfaceboardfortheZXR102800-4andZXR103800-8.
Itsupports3G/LTEradionetworkaccess.Itcanoperateastheprimaryorsecondarylink
forenterprisestoaccesstheInternettotransferaudio,data,andvideoles.
lSupportsTD-LTE,FDD-LTE,TD-SCDMA,WCDMA,andHSPA+.
lSupportsthefrequencybandsofmultiplenetworks,including:
àGSM/GPRSQuadBand(850,900,1800,and1900)
àTD-SCDMAB34,andB39
àWCDMAB1,B2,andB5
àLTEB38,B39,B40,andB41
àLTEFDDB1,B2,B3,B5,andB7
àGPSL1
lSupportsdifferentnetworkspeedsfordifferentnetworks.
àForFDD-LTEandTD-LTE,theboardsupportsnetworkspeedsof100Mbpsand
50Mbps.
àForTD-SCDMA,theboardsupportsnetworkspeedsof2.8Mbpsand2.2Mbps.
àForWCDMADC-HSPA+,theboardsupportsnetworkspeedsof42Mbpsand5.7
Mbps.
àForWCDMAHSDPA,theboardsupportsnetworkspeedsof21Mbpsand5.76
Mbps.
lSupportshot-swapping.
Panel
Figure9-7showsthepaneloftheRAC-PIU-LTEboard.
Figure9-7RAC-PIU-LTEBoardPanel
9-11
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
