ZXR10ZSRV2HardwareDescription
ParameterSpecication
Rate2.048Mbps×2
9.5RAC-SPIU-02HS
Overview
RAC-SPIU-02HSboardprovidesthefollowingfunctions:
lProvides2-wireserialportssupportingasynchronousorsynchronousdata
transmissionmode.
àForsynchronousdatatransmissionmode,theportscanbeconnectedtoDTEs
orDCEs.ThecircuitsidesupportstheV.24,V.35orX.21interfaces.TheV.24
interfacesupportsamaximumrateof115.2Kbps.TheV.35interfacesupports
amaximumrateof4.096Mbps.TheX.21interfacesupportsamaximumrateof
48Kbps.
àAsynchronousdatatransmissionmodesupportstheRS232interfacethat
supportsamaximumrateof115.2Kbps.
lSupportstheprocessingofvariousservices,suchasPPPandHDLC.
lSupportshotswapping.
lSupportsboardinformationqueryandtemperaturemonitoring.
Panel
ForthepaneloftheRAC-SPIU-02HSboard,seeFigure9-5.
Figure9-5FrontPaneloftheRAC-SPIU-02HSBoard
InterfaceProperty
Foradescriptionoftheinterfaceproperties,refertoT able9-14.
Table9-14InterfacePropertiesoftheRAC-SPIU-02HSBoard
PropertyDescription
ConnectortypeDB50
OperationalmodeAsynchronousorsynchronous
AppliedstandardV.24,V.35,X.21,orRS232
SupportedlinkprotocolPPP,HDLC,andFR
9-8
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 1800-2S Specifications

General

Model	ZXR10 1800-2S
Category	Network Router
MAC Address Table	8K
VLANs	4K
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Power Supply	AC: 100V~240V, 50Hz~60Hz
