3.4.4 CONNECTIONS
1). LAN Connection: This is a RJ45 LAN connector for 10/100 Base-T Ethernet. Use the Ethernet cable
(RJ45 to connect the device to a hub or a router in the network. Refer to Section 6: Power over
Ethernet Specifications for further detail.
Power Connection: The camera can be powered from either 12VDC or PoE. If the camera is powered via
PoE, refer to Section 6: Power over Ethernet Specifications for further detail.
Camera
Cable
Torx Wrench
Screw &
Plastic Anchor-3pcs
Quick Installation Guide
O-ring &
Waterproof Bracket
Bottom Pad
Installation Template
Adaptor & AC Plug
LAN cable
Power Adaptor
RJ-45
DC Power
