Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I

12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC

5.4.2 ADJUSTING ANGLE OF THE CAMERA

Steps:

1). Loosen the set screw located on the right side of the camera’s bracket by using the provided

Torx (T20 M4x23) wrench. Once the set screw is loosened, you can move the tilting joint and

the panning joint of the camera respectively.

2). Adjust the angle by moving the tilting joint and the panning joint.

Torx Wrench

Screw &

Plastic Anchor-3pcs

Quick Installation Guide

Installation Template

Adaptor & AC Plug

WALL CUSHION

CABEL CORE

❷

❶
