6.3.2 CAMERA UNIT WITH CONJOINED ACCESSORIES
1). Camera
2). Camera DIN connector: Connector to be inserted to the camera connector in the main unit
3). Pinhole Cover: Bracket to be installed behind a wall or ceiling to hold the camera inside
4). Surface Mount Bracket: Bracket to be installed on a wall or ceiling to hold the camera inside
5). Pan/Tilt Bracket: Bracket to be installed on a wall or ceiling for the camera’s angle adjustment. It
shall be combined with the rotate ring and the surface mount bracket for the complete installation.
❶
❸
❹
❷
* Model herein and its appearance are subject to change without any prior notice.
❺
