3xLogic VX-2A-B-IWD User Manual

Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
50
2). Insert the three anchor blocks into the holes on the ceiling.
3). Fix the bracket to the ceiling by inserting the tapping screws into the anchor blocks and
tightening them for the firm attachment.
4). This ceiling mount bracket normally requires a pendant mount cap to attach the camera. Refer
to the installation method in Pendant Mount Cap on the next page.
Plastic Anchor
Tapping Screw
Ceiling Mount Bracket
