5
Installation
Installation
Inserting the standard battery
Aastra 610d, 620d
Push the battery cover downwards until it disengages
from the locking mechanism and lift off. Insert the bat-
tery with the contacts downwards. Replace the battery
cover and push upwards until it snaps into place.
Aastra 630d
Undo the two screws on the back of the handset with a
suitable tool and remove the cover. Insert the battery
with the contacts downwards, close the battery com-
partment with the cover and screw back in place. Do
not damage the rubber seal when assembling.
Inserting the power battery
You can order a battery with higher capacity
(power battery) for the Aastra 620d and 630d
as an accessory (see page 62).
This battery has a thicker design so you need another
battery cover that protrudes approx. 6 mm beyond the
rear of the device.
Install the new battery cover as described above.
In the Aastra 620d you should remove any installed
fixing bracket beforehand.
