3 Removing and Installing
3.1 Turbocharger weight and transportation
Lifting gear with a sufficient load limit must be used for removing, installing and transport-
ing the turbocharger. The weight specified below applies to the heaviest variant possible.
Depending on the specification, the weight specified on the rating plate may be lower than
the standard value specified here.
Fig.11: Suspension of complete turbocharger unit
A Complete turbocharger unit without gas outlet casing
B Complete turbocharger unit with gas outlet casing
Product Weight of complete turbocharger unit [kg]
A150-M 1200
A155-M 1800
Table4: Weight of complete turbocharger unit
Page 29 / 194
