142 SV – R0…R4 Snabbguide för installation
R0-
R4
R5
R6-
R9
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
Installera tillvalsmoduler, om det finns några
Se kapitel Elektrisk installation i ACS580-01 (0.75 to 250 kW) hardware manual
(3AXD50000018826 [engelska]).
Sätt tillbaka kåpan
Se figur I på sidan 168.
1. Sätt flikarna på kåpans insida i motsvarande delar på kapslingen (1a) och tryck
sedan längst ned på kåpan (1b).
2. Dra åt skruvarna med en skruvmejsel.
Idrifttagningsinstruktioner finns i kapitel SV – Snabbguide för idrifttagning på sidan
409.
