AO2000 CONTINUOUS GAS ANALYZERS | OI/AO2000-EN REV. B 199
User pages
In addition to the system pages the user can set up so-called user pages
(see page 203).
Function blocks as sources
The values of all the function blocks in the system can be configured as a
source for the display. The source of the display of value entries or key en-
tries is also a function block that was created when configuring the display
elements. The display of the function block value is independent of the other
links of the function block.
Note: All sample components, auxiliary quantities, current outputs and cur-
rent inputs exist as function blocks in the system, i.e., all of these measured
quantities are displays of function blocks in the system. Technical Bulletin
"Function Blocks – Descriptions and configuration" contains complete infor-
mation on the "Function block" concept as well as detailed descriptions of the
individual function blocks.
Display element positioning on the screen
The display elements can be represented in two sizes. A maximum of three
large and six small display elements can be represented on a page. Large
and small display elements can be mixed with each other. The positions are
numbered as shown in the following figure. The numbering of the positions
corresponds to the arrangement of the number keys next to the display.
7
4
1
9
6
3
8
5
2
Views
The following views are available for screen configuration:
• Display overview (see page 200)
• Page overview (see page 201) and
• Parameter overview (see page 202).
