ABB CoreSense User Manual

D82 Installation Guide
Binary input point list
Point
Index
Name Event class assigned
(1, 2, 3 or none)
Name for state
when value is 0
Name for state
when value is 1
Description
0 Sys-Ready none OFF ON System ready
1 Sys-Warn none OFF ON System warning
2 Sys-Crit none OFF ON System critical
3 Hyd-Lev-Warn none OFF ON Hydrogen level warning
4 Hyd-Lev-Crit none OFF ON Hydrogen level critical
5 Hyd-Roc-Warn none OFF ON Hydrogen RoC warning
6 Hyd-Roc-Warn none OFF ON Hydrogen RoC critical
7 Moi-Lev-Warn none OFF ON Moisture level warning
8 Moi-Lev-Crit none OFF ON Moisture level critical
9 Moi-Roc-Warn none OFF ON Moisture RoC warning
10 Moi-Roc-Crit none OFF ON Moisture RoC critical
Transmitted
value
Scaling
Point
Index
Name Event Class
Assigned
(1, 2, 3, or
none)
Min
int/
flt
Max
int/
flt
Multiplier Offset Units Description
0 Hydrogen none / / 1 0 ppm
1 Hyd_Roc_Day none / / 1 0 ppm/day Hydrogen RoC
2 Hyd_Roc_Week none / / 1 0 ppm/week RESERVED - Hydrogen
RoC
3 Hyd_Roc_Month none / / 1 0 ppm/month RESERVED - Hydrogen
RoC
4 Oil_Temp none / / 1 0 Celsius Oil temperature
(moisture)
5 Moi_Aw none / / 0.01 0 aw Moisture
6 Moisture none / / 1 0 ppm Moisture
7 Moi_Day none / / 1 0 ppm/day Moisture
8 Moi_Week none / / 1 0 ppm/week RESERVED - Moisture
9 Moi_Month none / / 1 0 ppm/month RESERVED - Moisture
10 Input_1 none / / 0.01 0 mA 4–20 mA Input 1
11 Input_2 none / / 0.01 0 mA 4–20 mA Input 2
12 Input_3 none / / 0.01 0 mA 4–20 mA Input 3
