ABB FPTC-02 User Manual

DescriptionExample
value
NameIndex
SBC usage
Sets the absolute speed below which
the FSO module activates the brake
(SBC) while ramping.
0.0 rpmSSE/SS1 SBC
speed
SBC.15
0.0 rpm: The feature is not in use.
In the safety functions described in this
manual, this feature is not used. Make
sure that the value is 0.0 rpm.
1)
With the FPTC module, the recommended value is Immediate STO, but
other safety functions in the FSO module can require that the value is
Emergency ramp. With both settings, the FSO module always activates the
drive STO function immediately in motor overtemperature situations (SMT
function activated).
￭ FSE module and safety pulse encoder parameters
Set these parameters only when you use a safety pulse encoder and
the FSE-31 pulse encoder interface module with the FSO-21 module.
DescriptionExample
value
NameIndex
Activates the FSE-31 encoder interface
and shows the version of the encoder
parameter groups (91 and 92).
Version 1FSE 3X act
and par version
200.231
Shows the number of safety pulse en-
coders connected to the FSE module.
Single en-
coder CH1
Number of en-
coders
200.232
Activates the safety pulse encoder and
shows the version parameter group
S_ENCGEN.
Version 1Safe pulse en-
coder version
S_ENC-
GEN.01
Sets the action taken when there is a
problem with the FSE module.
STOFSE diagnostic
failure reaction
S_ENC-
GEN.11
STO: The FSO module goes into the
Fail-safe mode and activates the drive
STO function.
Note: This parameter is relevant only
when there are no active safety func-
tions.
60 Parameter settings
