Chapter 6 – Communication
NCAN-02 Installation and Start-up Guide 6-13
The NCAN Object
Dictionary
The NCAN Object Dictionary contains all Communication Objects. A
listing of the Object Dictionary is given below.
The serial communication properties of the drive, as well as drive
parameters, are detailed further in the drive documentation.
Communication Profile
Area
Index
(Hex)
Sub-
index
Name Type
Attri-
bute
Information
1000 0 Device Type Unsigned32 RO Describes the type of the device. Composed of two 16-bit fields (one for
device profile, the other for additional information. The object value of
the NCAN-02 is 0×0192, which corresponds to drive profile DSP-402
(0×192), and to additional information Frequency Converter (0×01).
1001 0 Error Register Unsigned8 RO Error register for the NCAN-02. Bit-encoded according to DS301/401.
Bit value 1 = Error occurred.
1003 0 Pre-defined Error Field Unsigned8 RO Number of errors occurred and listed at Sub-indexes 1 to A. Writing a
zero here deletes the list.
1 Pre-defined Error Field Unsigned32 RO List of errors.
The most recent error is at Sub-index 1. When a new error occurs,
previous errors move down the list. Error numbers comprise a 16-bit
error code (listed in Appendix B) and a 16-bit additional information
field (0 with NCAN-02). The error code is contained in the lower 2 bytes
(LSB), the additional information in the upper 2 bytes (MSB).
• • • • • • • • • • • •
A Pre-defined Error Field Unsigned32 RO
1005 0 COB ID SYNC
Message
Unsigned32 RW Identifier of the SYNC message.
The SYNC message controls the actions of PDOs that have the
transmission type Synchronous.
1006 0 Communication Cycle
Period
Unsigned32 RW Time between SYNC messages.
1007 0 Synchronous Window
Length
Unsigned32 RW Synchronous window length.
Default value: 0
µs (not used with NCAN-02).
1008 0 Manufacturer Device
Name
Visible string RO Module name.
The constant string is ABB NCAN-02.
1009 0 Manufacturer
Hardware Version
Visible string RO Version of the module hardware.
The constant string is HW V. 02.
Bit Description
0 Generic error
1 Current
2Voltage
3 Temperature
4 Communication error
5 Device profile specific
6 Reserved
7 Manufacturer specific
Slave to Master
Header
Byte
1 - 2 3 4 - 7 8
0001xxxxxx01000
Error
code
Error
register
Additional
error info
Unused
