ABB NCAN-02 User Manual

Appendix A – CANopen Error Codes
NCAN-02 Installation and Start-up Guide A-5
ACS 600 - Standard
Application Prg. v2.8/3.0
CANopen Error Drive Fault
Register
Bit
Code Meaning Name
b1 2120 Earth leakage EARTH FAULT
b1 2310 Continuous overcurrent OVERCURRENT
b1 2340 Short circuit SHORT CIRC
b2 3130 Phase failure SUPPLY PHASE
b2 3210 DC link overvoltage DC OVERVOLT
b2 3220 DC link undervoltage DC UNDERVOLT
b3 4100 Ambient temperature AMBIENT TEMP
b3 4210 Excess temperature device ACS 600 TEMP
THERMISTOR
b3 4310 Excess temperature drive MOTOR TEMP
b5 5300 Operating unit PANEL LOSS
b5 6200 User software USER MACRO
b5 7000 Additional modules I/O COMM
b5 7121 Motor blocked MOTOR STALL
b2 7123 Motor tilted OVERFREQ
b5 7305 Incremental sensor 1 fault ENCODER ERR
b5 7510 Serial interface 1 COMM MODULE
b5 8110 Process data monitoring AI < MIN FUNC
b5 9000 External error EXTERNAL FLT
b7 FF51 Device specific (1) LINE CONV
b7 FF52 Device specific (2) NO MOT DATA
b7 FF54 Device specific (4) RUN DISABLED
b7 FF56 Device specific (6) MOTOR PHASE
b7 FF63 Device specific (19) ID RUN FAIL
b7 FF64 Device specific (20) WRITE PROTCT
b7 FF65 Device specific (21) ID RUN SEL
b7 FF66 Device specific (22) PARAM LOCK
b7 FF67 Device specific (23) MOTOR STARTS
b7 FF68 Device specific (24) ID N CHANGED
b7 FF69 Device specific (25) MACRO CHANGE
b7 FF6A Device specific (26) UNDERLOAD
