ABB REF 54 Series Technical Reference Manual, General

1MRS750527-MUM
REF 54_
109
Feeder Terminal
Technical Reference Manual, General
Protocols & communication
• Uploading/downloading of the Relay Configuration Tool project (RCT) from/to
the feeder terminal for the Relay Configuration Tool.
• Parallel communication support: simultaneous use of the front and rear
connectors was not allowed earlier.
Hardware & mechanics
• New mechanics
• External display module
• New CPU module with a communication port for the external display module
• New hardware versions with an RTD/analog module
• One sensor channel added (total of 9 channels)
• Voltage threshold for digital inputs:
• Power supply 110/120/220/240 V AC or 110/125/220 V DC with the digital
input voltage range 110/125/220 V DC
• Power supply 24/48/60 V DC with the digital input voltage range 24/48/60/
110/125/220 V DC
Tools
• Uploading/downloading of the Relay Configuration Tool project (RCT in
CAP 505) from/to the feeder terminal via SPA or LON.
• Uploading/downloading of settings (CAP501/CAP505) from/to the feeder
terminal via the rear serial port RS-485 of REF 54_ using LON.
• Uploading of disturbance recordings to MicroSCADA and CAP 505 via SPA or
LON.
8.3.2. Configuration, setting and SA system tools
The following tool versions are needed to support the new functions and features of
the Release 2.0 revisions of REF 54_:
• CAP 505 Relay Product Engineering Tools; CAP 505 v. 2.0.0
• CAP 501 Relay Setting Tools; CAP 501 v. 2.0.0
• LNT 505 LON Network Tool; LNT 505 v. 1.1.1
• LIB 510 Library for MicroSCADA v. 8.4.3; LIB 510 v. 4.0.3
Table 8.3.1-4 New control functions
Function Description
COPFC Power factor controller
Table 8.3.1-5 New condition monitoring functions
Function Description
CMGAS3 Three-pole gas pressure monitoring
