112

1MRS750527-MUM

Feeder Terminal

Technical Reference Manual, General

REF 54_

Function blocks

• MEVO1A, MEVO1B, alternative measuring mode (DFT) added

• FREQ1ST_, maximum Operation time extended to 300 s instead of 120 s

For further information about the changes above, refer to the function block

descriptions on the CD-ROM Technical Descriptions of Functions.

Protocols & communication

• DNP 3.0 and Modbus support with RER 123 Bus Connection Module

• SPA support with RER 133

• Faster communication with SPA-ZC 302

• Faster communication with SPA-ZC 400 with limited GOOSE messages

Tools

• PQVO3Sd support added to Fault and Power Quality Reports in LIB 510

• Transducer Linearization Tool in CAP 505

8.6.2. Configuration, setting and SA system tools

The following tool versions are needed to support the new functions and features of

the Release 3.5 revisions of REF 54_:

• CAP 505 Relay Product Engineering Tools; CAP 505 v. 2.3.0-6

• CAP 501 Relay Setting Tools; CAP 501 v. 2.3.0-6

• LNT 505 LON Network Tool; LNT 505 v. 1.1.1-1

• MicroSCADA Pro Application Library LIB 510 *4.2

• REF 541/543/545 Connectivity package v. 1.2

• Communication Engineering Tool for COM610, SPA-ZC 40x or MicroSCADA

Pro SYS 600 and COM 500

• SCL Importer in MicroSCADA Pro SYS 600 and COM 500

Table 8.6.1-1 New protection functions

Function Description

FLOC Fault locator

Table 8.6.1-2 New power quality functions

Function Description

PQVO3Sd Short duration voltage variations
