ABB S800 User Manual

Section 3 Technical Data and Performance G3 Compliant
3BSE015969-600 A 115
G3 Compliant
The G3 compliant modules fulfills the severity level in the standard ISA-S71.04
Environmental Conditions for Process Measurement and Control Systems: Airborne
Contaminants.
The G3 compliant modules shall not be stored in more severe environment than G2
if the contacts are unconnected.
Transport and Storage Conditions
The S800 modules should be transported and stored in their original packaging.
Table 13. S800 Storage Conditions
Condition Range Standard
Temperature -40 to +70°C IEC/EN 61131-2
Humidity RH = 5 to 95%, no condensation
Altitude -500 to +3000 m
Pollution degree Degree 2 IEC 60664-1
Corrosive
atmosphere
< 1000 Angstrom copper corrosion over
28 days
ISA-71.04 
Severity level G2
Fall in package < 10 kg: 300 mm
10 - 40 kg: 300 mm
> 40 kg: 250 mm
Free-fall drop height in original product
package.
IEC/EN 61131-2
Shock 150 m/s
2
, 11 ms

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
