Climatic Operating Conditions Section 3 Technical Data and Performance
116 3BSE015969-600 A
Climatic Operating Conditions
Table 14. Climatic Operating Conditions
Condition Operative range Standard
Temperature
(1)
(1) Approvals are issued for +5 to +55°C.
0 to +55°C non-condensing
0 to +40°C compact MTUs or S800L
modules
on vertical DIN-rail, see 
Table 32, non-condensing
IEC/EN 61131-2
Temperature
cha
nge
3 °C/min
Humidity RH = 5 to 95%, no condensation
Altitude 2000 m
Pollution degree Degree 2 IEC 60664-1
Corrosive
atmosphere
<1000 Angstrom copper corrosion over
28
days
<2000 Angstrom copper corrosion over
28
days
ISA-71.04 
Severity level G2
ISA-71.04 
Severity level G3
Mechanical Operating Conditions
Table 15. Mechanical Operating Conditions
Operative range Standard
Vibration Test
Sinusoidal
Operational
5–9 Hz, amplitude 3,5 mm
9-150 Hz, acceleration 1,0g
1 octave/min
IEC/EN 61131-2
Shock 150 m/s
2
, 11 ms IEC/EN 61131-2
Emitted noise <55 dB (A)

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
