Functional Description Section 2 Product Description
28 3BSE015969-600 A
Functional Description
Product Configuration Examples
This section includes some basic configuration examples, to give you some ideas
about the use of S800 I/O.
PROFIBUS
An S800 I/O station can be connected to a PROFIBUS network using the Fieldbus
Communication Interface (FCI) CI801/CI840.
Figure 5. A PROFIBUS-DP Configuration Example
PROFIBUS master
Other PROFIBUS slaves S800 I/O stations with CI801/CI840
PROFIBUS

ABB S800 Specifications

General

Manufacturer	ABB
Mounting	DIN Rail
Power Supply	24 V DC
Protection Class	IP20
Certifications	CE, UL, ATEX
Number of Channels	Varies depending on module type
Model	S800
Communication Protocols	Profibus DP, Modbus
Redundancy	Yes (depending on module and communication interface)
